1. Core product identification

Brand and model: ABB 5SHY3545L0010 (3BHB013088R000)


Product type: IGBT power semiconductor module


Original factory certification: ABB genuine products (provide traceable serial number)


2. Key parameters and technical specifications

Rated voltage: 3300V/1700V (depending on configuration)

Rated current: 1200A -1600A

Package type: Press Pack IGBT

Applicable topology: multilevel frequency converter

Insulation level: UL Class 0 (highest level)

Working temperature range: -40 ° C to+125 ° C

3. Core functions and advantages

✅ Industrial grade reliability


Adopting ABB's patented trench grid technology, it has passed 100000+thermal cycle tests to ensure continuous operation in harsh scenarios such as metallurgy/mining.


✅ Accurate compatibility


Specially designed for ABB ACS1000 and ACS5000 series medium voltage frequency converters, perfect replacement for old models:

✦ 5SHY35L4510 ✦ 3BHB018162R0001 ✦ 5SHY3545L001


✅ Energy Efficiency Optimization Design


The VCE (sat) voltage decreased to 1.7V, reducing switch losses by 15% and significantly improving the system's energy utilization efficiency.


4. Typical application scenarios

Main Drive System for Rolling Mill in Steel Plant


Variable frequency control cabinet for mine hoist


Ship propulsion system power unit


Wind power converter power module group


Why choose us

✦ Genuine product guarantee: Provide ABB original factory inspection report and anti-counterfeiting traceability code

Global inventory: Europe/Asia warehouse spot delivery, supporting VMI supply chain

✦ Technical support: Free module installation guidance and fault diagnosis services provided

✦ Warranty commitment: 18 months of ultra long warranty, supporting failure analysis


The ABB 5SHY3545L0010 3BHB013088R000 IGBT module is a key spare part for high-voltage frequency converter maintenance, widely used for power unit repair of ACS5000 series frequency converters. As an authorized supplier of ABB, we ensure that every module passes dynamic load testing, matches the original IGBT driver board (such as 3BHE039203R0101), and solves faults such as overheating alarm (Fault Code: 2310) and output imbalance caused by power device aging. Provide a guide for configuring gate resistors and recommendations for selecting thermal interface materials to help equipment quickly resume production
