ABB CS513 3BSE000435R1 | S800 I/O Module | Isolated Digital Output, 16-Channel

Ensure Reliable and Safe Control of Your Critical Processes with High-Density, Isolated Digital Outputs

Product Overview

The ABB CS513 3BSE000435R1 is a high-performance, 16-channel isolated digital output module part of the renowned ABB S800 I/O family. Designed for integration within ABB's System 800xA and AC 800M controller environments, this module provides reliable and secure switching for actuators, solenoid valves, motor starters, and other critical field devices.

Its key strength lies in its individual channel isolation and high-density design, which maximizes cabinet space while minimizing wiring costs. Each output is protected against overloads and short circuits, ensuring maximum uptime and protection for your connected equipment. It is an essential component for discrete control applications in demanding industrial environments like oil & gas, power generation, chemical processing, and water treatment.

Key Features & Benefits

• 16 Isolated Output Channels: Features 16 individually isolated digital outputs, preventing fault propagation from one channel to another, enhancing system safety and reliability.

• High-Density Design: Saves valuable cabinet space and reduces wiring complexity compared to lower-density modules, leading to lower installation costs.

• Robust Output Protection: Each output channel is equipped with overload and short-circuit protection, safeguarding both the module and your connected field devices from electrical damage.

• High-Speed Operation: Supports fast switching times, making it suitable for applications requiring rapid control responses.

• Hot Swappable: Allows for module replacement and maintenance without powering down the entire I/O system, significantly reducing downtime (requires compatible base unit and redundant power configuration).

• Seamless System Integration: Fully compatible with ABB's flagship System 800xA and AC 800M controllers, ensuring easy configuration and diagnostics within a unified engineering environment.

Technical Specifications

• Power Dissipation | Typical X.X W |
  | Connection | Via S800 I/O field terminal (e.g., TU810 3BSE013240R1) |
  | Compatible Controllers | AC 800M, AC 700F, PLCs via PROFIBUS DP (with appropriate master interface) |
  | Software Support | ABB System 800xA, Control Builder, Automation Builder |
  | Certifications | cULus Listed, ATEX, IEC Ex, CE, RoHS, DNV GL |
  | Order Number | 3BSE000435R1 |
  | Model Code | CS513 |

Typical Applications

The CS513 digital output module is designed for a wide range of industrial control applications:

• Controlling solenoid valves for process control

• Actuating motor starters and contactors

• Operating indicators, alarms, and warning lights

• Driving relays and other logic elements

• Discrete control in batch and continuous process automation

• Machinery and packaging line control

Compatible Systems & Products

• I/O Base Units: Mounts onto S800 I/O digital base units (e.g., SD821 | 3BSE008514R1, SD822).

• Field Terminals: Requires a corresponding field terminal block (e.g., TU810 | 3BSE013240R1 for 16 channels) for wiring.

• Controllers: AC 800M, AC 700F, and other PLC systems via PROFIBUS DP adapters.

• Engineering Tools: Configured and commissioned within ABB's Control Builder or Automation Builder engineering suites.

Why Buy From Us?

• Genuine ABB Product: We supply only 100% authentic, new ABB products, backed by the full manufacturer's warranty and traceability.

• Expert Support: Our technical sales team has extensive knowledge of industrial automation and can provide pre-sales support to ensure this is the right component for your system.

• Fast Global Shipping: We understand the urgency of industrial needs. We ship reliably from our regional warehouses to get you the parts you need, fast.

• Secure & Easy Ordering: We offer multiple secure payment methods and streamlined procurement processes for business customers.

Ordering Information

To purchase the ABB CS513 3BSE000435R1 or to discuss your project requirements, please contact our sales team. Remember to specify the required quantity and inquire about compatible base units and terminal blocks if needed.

Full Part Number: 3BSE000435R1
Model: CS513

⚠️ Important Note: This module requires an S800 I/O base unit (e.g., SD821) and a corresponding field terminal block (e.g., TU810) for operation. Always verify system compatibility using official ABB documentation.
