ABB PM802F AC 800M Controller Module

Product Overview

The ABB PM802F is a robust and high-performance Controller Module from the acclaimed AC 800M family, serving as a powerful engine for ABB's System 800xA and other automation suites. Designed for medium to high-complexity applications, this controller delivers the perfect balance of processing power, memory capacity, and connectivity for a wide range of industrial automation tasks.

As a central processing unit (CPU), the PM802F executes control logic, manages communication networks, and interfaces with a vast array of I/O modules. It is engineered for reliability in continuous process industries and complex machine control, providing deterministic performance essential for critical operations.

Key Features & Technical Specifications

• Enhanced Processing Power: Features a powerful processor capable of handling complex control algorithms, extensive I/O counts (up to 1000+ variables), and demanding computational tasks with fast cycle times.

• Ample User Memory: Offers significant memory capacity for storing large application programs, data logs, and user-defined function blocks, providing flexibility for sophisticated projects.

• Integrated Connectivity: Equipped with multiple built-in communication ports:

  • Ethernet (MB300): For integration with System 800xA operator stations and peer-to-peer communication.

  • Serial (COM1): For connecting to legacy devices, printers, or other serial equipment.

  • CI854 (optional): Supports additional fieldbus protocols like Profibus DP, enabling connection to S800 I/O and other devices.

• High Availability Ready: Can be configured in a redundant pair with another PM802F or compatible controller for critical applications requiring maximum uptime and fault tolerance.

• Robust Industrial Design: Built to operate 24/7 in harsh industrial environments with a wide temperature range and high immunity to electrical noise and vibration.

• IEC 61131-3 Programming: Programmed using ABB's Control Builder M engineering tool, which supports all standard languages (LD, FBD, IL, SFC, ST) for flexible and efficient code development.

Typical Technical Data:

• Manufacturer: ABB

• Part Number: PM802F

• Product Type: Programmable Logic Controller (PLC) / Process Controller

• Series: AC 800M

• System Compatibility: System 800xA, Compact HMI, Third-party systems via OPC

• Software: Control Builder M

Primary Applications

The PM802F is versatile enough for a broad spectrum of industries and applications:

• Process Industries: Control of batch and continuous processes in chemical, pharmaceutical, and food & beverage plants.

• Energy Management: Building Automation Systems (BAS), control of HVAC, lighting, and power distribution in large facilities.

• Water & Wastewater: Management of pumping stations, filtration plants, and chemical dosing systems.

• Discrete Manufacturing: Complex machine control, assembly line automation, and material handling systems.

• Marine & Offshore: Auxiliary system control on vessels and offshore platforms.

Compatibility & System Integration

The PM802F is a core component of ABB's modern automation architecture:

• DCS/PLC: The central CPU of an AC 800M controller rack.

• I/O Systems: Directly compatible with ABB's S800 I/O modules (via a Profibus DP communication interface like the CI854 module) for a seamless and expansive I/O architecture.

• Networking: Integrates effortlessly into industrial Ethernet networks for communication with HMI panels, SCADA systems, and other controllers.

Why Choose the ABB PM802F?

• Proven Reliability: Part of the widely trusted AC 800M family, known for its robustness and longevity in industrial settings.

• Scalability: Offers a future-proof platform; programs can often be migrated to more powerful controllers (like PM803/4/5) within the same family as needs grow.

• Unified Engineering Environment: When used with System 800xA, it benefits from a single integrated engineering environment for design, operation, and maintenance, reducing lifecycle costs.

• Global Support: Backed by ABB's global service and support network, ensuring long-term availability of expertise and spare parts.
