The
REF615E-E is an enhanced medium-voltage (MV) feeder protection relay, part of ABB’s industry-leading Relion® 615 Series. Engineered to address the evolving needs of smart grids and industrial power systems, this relay combines robust protection capabilities with advanced digital features—delivering precise fault detection, seamless connectivity, and proactive system monitoring.
Ideal for MV feeders in utility networks, industrial plants, and commercial infrastructure, the REF615E-E ensures fast fault isolation, minimizes downtime, and supports integration with modern digital substation architectures. Its rugged design and flexible configuration make it suitable for both new installations and retrofits, aligning with global standards for power system safety and efficiency.
Equipped with advanced protection algorithms—including adaptive overcurrent settings and directional earth fault detection—to pinpoint faults accurately, avoiding unnecessary feeder tripping and improving grid stability.
Gigabit Ethernet ports and support for IEC 61850 Ed. 2 (including Sampled Values) enable integration with digital substations and smart grid platforms, facilitating real-time data exchange and remote control.
±0.1% accuracy for current and voltage measurements ensures reliable data for load monitoring, energy management, and grid optimization—eliminating the need for separate metering devices.
A 3.5-inch color LCD display with touch-sensitive navigation simplifies on-site configuration, while a web-based HMI allows remote access via any browser—reducing setup time and maintenance visits.
Withstands wide temperature ranges (-40°C to +70°C), vibration, and electrical interference, making it suitable for harsh environments like outdoor substations, industrial plants, and remote renewable energy sites.
Built-in condition monitoring (e.g., power supply health, relay self-tests) and event logging (up to 2000 fault records) provide early warnings of potential issues, extending equipment lifespan and reducing unplanned downtime.
Customizable logic blocks and support for add-on functions (e.g., synchrocheck, load shedding) allow tailoring to specific network needs, while compatibility with ABB’s Relion® ecosystem enables easy expansion.
The REF615E-E is trusted in critical power systems worldwide, including:
- Utility Distribution Grids: Protection of MV feeders serving residential, commercial, and industrial zones, with smart grid integration for demand response.
- Industrial Facilities: Safeguarding feeders powering motors, compressors, and production lines in oil refineries, chemical plants, and manufacturing sites.
- Commercial & Infrastructure: MV feeder protection in data centers, airports, railways, and high-rise buildings—where uninterrupted power is critical.
- Renewable Energy Plants: Controlling feeders connecting solar farms, wind parks, and battery energy storage systems (BESS) to the grid, ensuring compliance with grid codes.
- Mining & Heavy Industry: Withstanding harsh conditions to protect feeders in mines, steel mills, and cement plants.
The REF615E-E seamlessly integrates with:
- ABB Relion® 600/650 Series relays (for coordinated protection schemes across MV/LV networks).
- ABB MicroSCADA Pro and System 800xA DCS (for centralized monitoring and control).
- ABB Ability™ Power Grids platform (for predictive maintenance, grid analytics, and remote asset management).
- Third-party SCADA/EMS systems (via IEC 61850, Modbus, or DNP3.0).
- Digital substation components (merging units, intelligent electronic devices/ieds) for sampled values-based protection.
Designed for efficiency and ease of use:
- Panel-mounted (144x144 mm standard cutout) for straightforward integration into existing control cabinets.
- Front-accessible USB-C port and Ethernet connections for fast configuration, firmware updates, and data retrieval.
- Hot-swappable communication modules (optional) allow upgrades without powering down the relay.
- ABB PCM600 configuration software provides a unified interface for setup, testing, and diagnostics—simplifying maintenance workflows.
ABB delivers comprehensive support for the REF615E-E throughout its lifecycle:
- 24/7 Global Technical Support: Access to specialized power protection engineers via phone, email, or remote troubleshooting tools.
- Commissioning & Testing: Professional on-site services to verify protection settings, network integration, and compliance with local standards.
- Training Programs: Customized courses (in-person or online) for engineers and technicians, covering relay configuration, fault analysis, and smart grid integration.
- Warranty & Maintenance: 2-year standard warranty, with optional extended coverage and preventive maintenance packages tailored to your network needs.
- Obsolescence Management: Proactive notifications and migration plans to ensure long-term compatibility with evolving grid technologies.
- Proven Reliability: Deployed in 60,000+ MV networks globally, with a 99.9% uptime rate and compliance with strict IEC standards.
- Smart Grid Compatibility: IEC 61850 Ed. 2 support ensures future-readiness for digital substation and smart grid upgrades.
- Total Cost Savings: Reduces downtime via fast fault isolation, eliminates the need for separate meters, and lowers maintenance costs with predictive diagnostics.
- Global Expertise: ABB’s network of 100+ service centers provides local support, fast spare parts delivery, and on-site assistance.
- Safety Compliance: Meets international safety standards (UL, CSA, ATEX) for use in hazardous and regulated environments.
To order the REF615E-E or inquire about pricing, availability, or custom configurations:
- Contact your local ABB Power Grids sales representative or authorized distributor.
- Specify model number: REF615E-E, and note key requirements (e.g., power supply voltage, communication protocols).
- Recommended accessories:
- ABB PCM600 configuration software (license required).
- Gigabit Ethernet and RS485 communication cables.
- Test tools for relay calibration and commissioning.
- IP54-rated front protective cover (for dusty or wet environments).
- Mounting hardware and terminal blocks.
