Product Overview

The ABB DSTA131 (Ordering Code: 57310001-P) is a high-performance, pilot-operated directional control valve designed for demanding industrial applications. As a key component in pneumatic systems, it reliably directs or stops airflow to control the movement of actuators like cylinders and grippers.

This 5/2-way single solenoid valve is known for its robust construction, exceptional flow rate, and energy efficiency. It forms an integral part of automation solutions across various sectors, including packaging, automotive, and material handling. The DSTA131 is engineered for easy integration and long service life, ensuring maximum uptime and productivity for your operations.

Technical Specifications

Note: Specifications may vary depending on the specific model. Always refer to the official datasheet for precise details.

Product Features

• High Flow Capacity: The optimized internal design provides a high Cv value, enabling faster cylinder speeds and improved machine cycle times.

• Low Power Consumption: Advanced solenoid technology ensures minimal energy usage, reducing operational costs and allowing use with compact PLC outputs.

• Robust Metal Housing: The durable aluminum die-cast body offers excellent heat dissipation and high resistance to impact and harsh industrial environments.

• Excellent Sealing (IP65): The IP65 rating guarantees reliable operation even in dusty conditions or when exposed to wash-downs with water jets.

• Manual Override: Integrated manual override allows for easy testing, commissioning, and manual cycling of the system during setup or troubleshooting.

• Long Service Life: High-quality materials and precision engineering ensure millions of reliable cycles, minimizing maintenance needs and downtime.

• Easy Installation & Maintenance: Modular design and standardized interfaces allow for quick mounting, connection, and potential bank assembly.

Application Areas

The ABB DSTA131 directional control valve is versatile and suitable for a wide range of industrial automation applications, including:

• Packaging Machinery: Controlling clamping, sealing, and product transfer operations.

• Automated Assembly Lines: Operating actuators for part placement, pressing, and robotic tool changers.

• Material Handling Equipment: Driving pneumatic cylinders in conveyor systems, palletizers, and sorting machines.

• Automotive Manufacturing: Used in welding fixtures, clamping units, and part handling systems.

• Food and Beverage Industry: Suitable for applications requiring reliable pneumatic control (with appropriate air quality).

• General Industrial Machinery: Any application requiring precise and reliable directional control of pneumatic actuators.



Document Downloads

Access the essential technical documents for the ABB DSTA131 valve here. All files are in PDF format.

• Datasheet: [ABB DSTA131 57310001-P Technical Datasheet.pdf] – Detailed technical specifications, dimensional drawings, and ordering codes.

• Installation & Operating Manual: [ABB DSTA131 User Manual.pdf] – Step-by-step instructions for installation, wiring, operation, and maintenance.

• Safety Instructions: [ABB DSTA131 Safety Guidelines.pdf] – Important safety information for installation and operation.

• CAD Drawings: [ABB DSTA131 3D Model.zip] – 2D drawings and 3D models for easy integration into your machine design.

Technical Support

We are here to help you get the most out of your ABB products.

• Need Immediate Help? Visit our comprehensive FAQ section for quick answers to common questions.

• Can't Find What You're Looking For? Contact our expert technical support team via our Support Contact Form. Please have your product model and serial number ready.

• Looking for Local Support? Find an ABB authorized partner or service center near you using our Partner Locator tool.

For urgent inquiries, please call our customer service hotline at +8618250705533.

Call to Action: Ready to integrate the reliable ABB DSTA131 into your system? Request a Quote today or Contact a Sales Representative to discuss your specific needs.
